Object Info
Object Name NGC3576 (right) and NGC3603 (left)
Type Emission Nebula;
Centered at: RA: 11h 12m 36.5s Dec: -60°50'32"
Constellation Carina
Image Field 76 x 56 arcminutes
Notes This is a hydrogen-alpha, two-part mosaic taken through
a Schuler (10nm) Hydrogen Alpha Filter.
Taken from: Tin Shed Observatory
Gold Coast, Queensland
Long - Lat = 153:23.54E - 27:56.8S
On: 29th-April-2005



Image Info
Telescope Intes MN61 - 6" f6 Maksutov-Newtonian
Focal Length 900 millimetres
Telescope guiding External via ST-5c at 1000mm
Telescope control Astrometric Sky Walker II
CCD camera SBIG ST-10xe
Camera cooling Regulated Thermoelectric
Camera pixels 2184 x 1472 x 6.8um
Image scale 1.5 arcseconds per pixel unbinned
Processed with: Mira A/P, Maxim DL, AIP4Win, CCDSharp, Photoshop
Hydrogen Alpha Exposures Ha = 90 minutes each half
Image Calibrations All sub-images Dark Subtracted, Flat Fielded.
