Object Info
Objects NGC7293 - The Helix nebula
Type Planetary Nebula IV + III
Centered at: RA: 22:29.6 DEC: -20:48
Constellation Aquarius
Magnitude 7.3
Size 2 light years
Distance 425 light years (the closest planetary nebula to us)
Age ?
Dimensions > 13 arcminutes
Image Field 31'07" x 20'52"
Notes Schuler 10nm Hydrogen Alpha was used for the Ha luminance image.
Taken from: Tin Shed Observatory
Gold Coast, Queensland
Long - Lat = 153:23.54E - 27:56.8S
On: Ha 5th August 2003. RGB reused from 27th July 2003



Image Info
Telescope Celestron C11 @ f5.9
Focal Length 1652 millimetres
Telescope guiding Guided by ST5c on Synta 102mm f5 (500mm)
Telescope control Astrometric Sky Walker II
CCD camera SBIG ST-10xe
Camera cooling Regulated Thermoelectric
Camera pixels 2184 x 1472 x 6.8um
Image scale 0.7 arcseconds per pixel
Processed with: Mira A/P, Maxim DL, AIP4Win, CCDSharp, Photoshop
Exposure times Ha,R,G,B = 65,25,25,25 RGB taken as 5-minute unbinned subimages.
Image Calibrations All sub-images Dark Subtracted, Flat Fielded.
